A Sloped Tile Shower Pan with a Linear Drain. Tile contractor Tom Bouchard shows how to make a tile-ready, watertight sloped shower pan with a linear drain using Schluter Kerdi-Board, Kerdi membrane, and thinset mortar. Linear Drain ShowerSlope ™ Shower Base. When it comes to installing linear drains, the Linear Drain ShowerSlope ™ is the ideal solution. Each Linear Drain ShowerSlope™ is equipped with a 1-1/4' leading edge designed with a linear drain slot.

Features & Benefits

• Pre-sloped ready to tile pan eliminates need for traditional mud bed installations
• Lightweight and durable. Easy to transport and handle during installation
• Factory installed, code approved waterproofing meets ANSI A118.10 requirements
• Factory installed drain assembly
• Can quickly and easily be modified to size on site
• Code approved, Meets IAPMO-PS- 46
• Component of LATICRETE® Lifetime Warranty*
• Single source responsibility
• Works in conjunction with LATICRETE tile and stone installation materials
• * See DS 230.99 for complete warranty information.

• Product #: 93XX-XXXX-XXX
• Packaging Sizes:

  Center Drains

  48' x 48' (122 cm x 122 cm) ABS, PVC or BRS
  36' x 60' (91 cm x 152 cm) ABS, PVC or BRS
  36' x 48' (91 cm x 122 cm) ABS, PVC or BRS
  48' x 60' (122 cm x 152 cm) ABS, PVC or BRS


  Off Center Drain

  38' x 66' (96 cm x 168 cm) ABS, PVC or BRS.


  The HYDRO BAN Pre-Sloped Shower Pans are also available in custom sizes and shapes.


  Each pre-sloped shower pan is packaged with one HYDRO BAN Pre-Sloped Shower Pan, one HYDRO BAN Preformed Curb and one tube of HYDRO BAN Adhesive & Sealant. All pans are available with either a PVC or ABS drain connection. A Custom HYDRO BAN Pre-Sloped Shower Pan is also available with a brass waste line connection when needing a metal drain due to municipal building or plumbing codes. The HYDRO BAN Drain Grates are sold separately in brushed, polished or oil rubbed bronze finishes.


  When ordering a HYDRO BAN Pre-Sloped Shower Pan check with local code official to determine whether a PVC, ABS or BRS (metal drain connection is required).

• Part of System: LATICRETE®

Product Data Sheets

• DS.031.0 (English)
• DS.031.0E (Español)
• DS.031.0F (Français)

Approvals, Certifications and Environmental

• AU-45 IAPMO PS-106 Tileable Shower Receptors and Shower Kits

Marketing Information

• DS-230.6 Shower System and Drains Brochure (English/Español)
• T-2207_ENG-S Brochure (English/Español)
• DS.010.8 Barrier-Free Shower Brochure

Warranties

• DS 025.0 25 Year System Warranty
• DS 230.10 10 Year System Warranty
• DS 230.13 1 Year Product Warranty
• DS 230.99 LATICRETE Lifetime System Warranty (United States and Canada)

Installation Information

• 36 x 48 Pre-Sloped Shower Pan (English)
• 36 x 60 Pre-Sloped Shower Pan (English)
• 38 x 66 Pre-Sloped Shower Pan (English)
• 48 x 48 Pre-Sloped Shower Pan (English)
• 48 x 60 Pre-Sloped Shower Pan (English)
• DS.012.5 Barrier-Free Installation Manual

Suitable Substrates

• Concrete
• Exterior Glue Plywood
• Cement Backer Board
• Oriented Strand Board (OSB)

Common Applications

Watch Tips From Our Pros!

View tips for product installation, demonstrations, get project inspiration and more on our YouTube channel.

Training & Seminars

Sign up for our free 24/7 online training, or attend our hands-on Profit Through Knowledge (PTK) classes.

Contact Technical Services

Questions about LATICRETE® products? Contact us!

1-800-243-4788

We provide up-to-date Slot Drain specification sheets for the use of architectural and engineering specifying, including submittals, spec sheets, CAD drawings, product guide and industrial application guide.

CSA Certification Information

Installation

Brochures

Our professional staff are available to provide suggested layouts as well as specification guidelines for tender purposes. Shop drawings are available upon receipt of purchase orders.

FLOW RATES

Slot Drain is customized to suit special requirements and is available in a variety of depths to compliment flow requirements. Stainless steel is available up to depths of 70”.

Slot Drain has the ability to handle high capacity drainage and has proven itself successful in hundreds of installations.

Slot Drain’s flow rates vary depending on the width the slot is set at. A standard piece of drain section with a slot width of 1 1/4” has a flow rate of 33 GPM (gallons per minute) or .074 cfs (cubic feet per second) for 100“ of drain. Depending on customers’ needs, any flow rate can be attained by increasing the depth of the trough.

Concrete Slot Drain Pan Kits

Slot Drain’s slope is 1/16” per foot and the width of the slot may be set to best suit the installation as well, ranging from 1/2“ to 1 1/4”.

PITS AND JUNCTION BOXES

Slot Drain has 90° and 45° elbows that are available to allow the drain to virtually go anywhere it is desired, minimizing construction labour costs.

Pits and junction boxes are in a variety of sizes to suit your needs.

Slot Sink Drain Pan

CLEANING

Slot Drain Pan Stainless Steel

Where desired, flush valves are available and are added to the drain ends. They function to remove any sediment and help keep the drain sections clean and sanitary. Car washes, for example, can reuse water from the car wash by placing a sump in the pit/catch basin. They can also be connected to a cold water valve and can be set with time control in order to automatically flush the system when needed or can be turned on manually via a valve/knob.

Slot Drain For Concrete Sink

If manual cleaning is ever required, cleaning paddles are also supplied with your purchase. The paddles have the same profile as the Slot Drain section and are inserted through the slot, then twisted 90 degrees and moved along the drain.
